EA 40×40×4 - Section Properties

The EA 40×40×4 is a equal angle with a mass of 2.42 kg/m, an overall depth of 40 mm and width of 40 mm. It has a cross-sectional area of 3.08 cm², a second moment of area Iᵧ of 4.47 cm⁴, a plastic modulus Wₚₗ,ᵧ of 0 cm³, to BS EN 1993-1-1:2005 / BS EN 10056-1:1999 (SCI P363 Blue Book).

Mass

2.42 kg/m

Depth

40 mm

Width

40 mm

Area

3.08 cm²

PropertiesCapacity

mass (kg/m)2.42

h (mm)40

b (mm)40

t_w (mm)4

I_y (cm⁴)4.47

I_z (cm⁴)4.47

i_y (cm)1.21

i_z (cm)1.21

I_u (cm⁴)7.09

I_v (cm⁴)1.86

i_u (cm)1.52

i_v (cm)0.777

A (cm²)3.08
