Tee 152×76×12 - Section Properties

The Tee 152×76×12 is a structural tee with a mass of 11.5 kg/m, an overall depth of 76.1 mm and width of 152.2 mm. It has a cross-sectional area of 14.6 cm², a second moment of area Iᵧ of 58.5 cm⁴, a plastic modulus Wₚₗ,ᵧ of 16.9 cm³, to BS EN 10365:2017 (SCI P363 Blue Book).

Mass

11.5 kg/m

Depth

76.1 mm

Width

152.2 mm

Area

14.6 cm²

PropertiesCapacity

mass (kg/m)11.5

h (mm)76.1

b (mm)152.2

t_w (mm)5.8

t_f (mm)6.8

I_y (cm⁴)58.5

I_z (cm⁴)200

i_y (cm)2

i_z (cm)3.7

W_el,y flange (cm³)41.9

W_el,y toe (cm³)9.41

W_el,z (cm³)26.3

W_pl,y (cm³)16.9

W_pl,z (cm³)40.1

A (cm²)14.6
