CHS 33.7×4 - Section Properties

The CHS 33.7×4 is a circular hollow section with a mass of 2.93 kg/m, an overall depth of 33.7 mm and width of 33.7 mm and a wall thickness of 4 mm. It has a cross-sectional area of 3.73 cm², a second moment of area Iᵧ of 4.19 cm⁴, a plastic modulus Wₚₗ,ᵧ of 3.55 cm³, to BS EN 10210-2:2006 (SCI P363 Blue Book).

Mass

2.93 kg/m

Diameter

33.7 mm

Wall thickness

4 mm

Area

3.73 cm²

PropertiesCapacity

mass (kg/m)2.93

t (mm)4

I_y (cm⁴)4.19

i_y (cm)1.06

W_el,y (cm³)2.49

W_pl,y (cm³)3.55

I_t (cm⁴)8.38

W_t (cm³)4.97

A (cm²)3.73

SA/m (m²/m)0.106

SA/t (m²/t)36.1
